轴承
型号 |
内径
mm in |
外径
mm in |
宽度
mm in |
倒角
mm |
额定载荷(KN) |
钢球参数 |
极限转速 |
重量 |
Dynamic
Cr |
Static
Cor |
No |
Size
mm |
Grease
r/min |
Oil
r/min |
kg |
693开
693闭 |
3 .1181 |
8 .3150 |
3 .1181
4 .1574 |
0.15 |
0.43 |
0.19 |
6 |
1.588 |
44000 |
52000 |
0.0006 |
694 |
4 .1574 |
11 .4330 |
4 .1574 |
0.15 |
0.55 |
0.25 |
8 |
1.588 |
38000 |
47000 |
0.0018 |
695 |
5 .1969 |
13 .5118 |
4 .1574 |
0.20 |
0.83 |
0.39 |
8 |
2.0 |
34000 |
43000 |
0.0022 |
696 |
6 .2362 |
15 .5906 |
5 .1969 |
0.20 |
1.13 |
0.56 |
8 |
2.381 |
32000 |
40000 |
0.0039 |
697 |
7 .2756 |
17 .6693 |
5 .1969 |
0.30 |
1.55 |
0.78 |
7 |
3.0 |
30000 |
38000 |
0.0053 |
698 |
8 .3150 |
19 .7480 |
6 .2362 |
0.30 |
2.03 |
1.05 |
7 |
3.5 |
28000 |
36000 |
0.0072 |
699 |
9 .3543 |
20 .7874 |
6 .2362 |
0.30 |
1.91 |
0.99 |
8 |
3.175 |
27000 |
34000 |
0.0075 |
6900 |
10 .3937 |
22 .8661 |
6 .2362 |
0.30 |
2.07 |
1.12 |
9 |
3.175 |
25000 |
32000 |
0.0100 |
6901 |
12 .4724 |
24 .9449 |
6 .2362 |
0.30 |
2.20 |
1.24 |
10 |
3.175 |
20000 |
28000 |
0.0110 |
6902 |
15 .5906 |
28 1.1024 |
7 .2756 |
0.30 |
2.64 |
1.51 |
10 |
3.50 |
19000 |
26000 |
0.0170 |
6903 |
17 .6693 |
30 1.1811 |
7 .2756 |
0.30 |
2.79 |
1.66 |
11 |
3.50 |
18000 |
24000 |
0.0180 |
6904 |
20 .7874 |
37 1.4566 |
9 .3546 |
0.30 |
5.05 |
3.08 |
10 |
5.0 |
17000 |
22000 |
0.0360 |
6905 |
25 .9843 |
42 1.6535 |
9 .3546 |
0.30 |
5.33 |
3.38 |
11 |
5.0 |
14000 |
18000 |
0.0410 |
6906 |
30 1.1811 |
47 1.8504 |
9 .3546 |
0.30 |
5.85 |
4.0 |
13 |
5.0 |
13000 |
15000 |
0.0450 |
|
|
|
